IPCY 1W 8MP 24/7 MZ DL

8MP 4K Motorized Lens Dual-Light Bullet IP Security Camera with AI Face Detection, Human & Vehicle Detection, VCA Analytics & PoE

Product Overview

The IPCY 1W 8MP 24/7 MZ DL is a professional-grade 8MP 4K Ultra HD bullet IP security camera engineered for high-resolution surveillance, intelligent video analytics, and dependable day-and-night monitoring.

Featuring a 1/2.8-inch Sony IMX415 CMOS image sensor, a 2.7–13.5mm motorized varifocal lens, and advanced AI-powered detection capabilities, this camera delivers exceptional image clarity and flexible coverage for residential, commercial, and industrial security applications.

Its intelligent video analytics include face detection, human and vehicle detection, line-crossing detection, area entry and exit detection, and perimeter intrusion detection.

The camera also incorporates Smart Dual-Light technology, combining infrared and warm white-light illumination to provide effective nighttime surveillance at distances of approximately 98–131 feet (30–40 meters).

With H.265/H.264 video compression, IEEE 802.3af PoE, ONVIF 23.12 compatibility, and a rugged IP67-rated weatherproof housing, the IPCY 1W 8MP 24/7 MZ DL offers a comprehensive solution for modern IP surveillance systems.

Key Features

  • 8MP 4K Ultra HD Resolution – Crystal-clear 3840 × 2160 video imaging.

  • Sony IMX415 Image Sensor – High-performance 1/2.8-inch CMOS technology for detailed surveillance footage.

  • 2.7–13.5mm Motorized Varifocal Lens – Adjustable field of view for flexible installation and precise monitoring.

  • AI Face Detection – Intelligent facial detection for enhanced security monitoring.

  • Human & Vehicle Detection – Advanced object classification helps identify people and vehicles.

  • VCA Intelligent Video Analytics – Supports line crossing, area entry, area leaving, and area intrusion detection.

  • Smart Dual-Light Night Vision – Infrared and warm white-light illumination for enhanced nighttime monitoring.

  • Night Vision Range – Approximately 98–131 feet (30–40 meters).

  • Low-Light Performance – Minimum illumination of 0.01 Lux.

  • Built-In Microphone – Captures audio alongside video surveillance.

  • H.265/H.264 Dual-Stream Compression – Efficient video encoding to optimize network bandwidth and storage.

  • Wide Dynamic Range (WDR) – Improves image visibility in challenging lighting conditions.

  • Advanced Image Processing – AWB/MWB, 2D/3D DNR, privacy masking, image mirroring, and ROI.

  • Power over Ethernet (PoE) – IEEE 802.3af support for simplified network installation.

  • ONVIF 23.12 Compatibility – Integration with compatible third-party NVRs and video management systems.

  • P2P Cloud Connectivity – Convenient remote access through supported applications.

  • IP67 Weatherproof Housing – Durable construction for demanding indoor and outdoor installations.

  • 4000V Lightning Protection – Additional electrical surge protection.

Intelligent AI Detection & Video Analytics

The camera features advanced intelligent video analytics designed to improve surveillance accuracy and support proactive security monitoring.

Supported Smart Detection Features:

  • Face Detection

  • Human Detection

  • Vehicle Detection

  • Line Crossing Detection

  • Area Entry Detection

  • Area Leaving Detection

  • Area Intrusion Detection

  • Motion Detection

These intelligent detection functions help security operators monitor designated areas, identify relevant activity, and improve overall surveillance efficiency.

Smart Dual-Light Night Vision

The IPCY 1W 8MP 24/7 MZ DL features four integrated infrared and warm-light illuminators designed for reliable nighttime surveillance.

Night Vision Specifications:

  • Lighting Technology: Infrared + Warm White Light

  • Integrated Lights: 4 Dual-Light Illuminators

  • Illumination Distance: 98–131 feet (30–40 meters)

  • Lighting Control: Automatic or Manual

  • Adjustable Brightness: 0–100%

  • Low-Light Sensitivity: 0.01 Lux

The combination of infrared and supplemental warm lighting provides flexible nighttime monitoring for various security environments.

Technical Specifications

Camera & Imaging

SpecificationDetails
ModelIPCY 1W 8MP 24/7 MZ DL
Camera Type8MP Motorized Dual-Light Bullet IP Camera
Image Sensor1/2.8" Sony IMX415 CMOS
Sensor Resolution8 Megapixels
Effective Pixels3840 (H) × 2160 (V)
Processor / SoCSigmastar SSC378DE
Lens2.7–13.5mm Motorized Varifocal
Minimum Illumination0.01 Lux
Exposure ShutterAuto / Manual, 1/10s – 1/8000s
Day/Night ModesAuto / Day / Night
Day/Night SwitchingActive / Passive / Scheduled
Anti-FlickerAuto / 50Hz / 60Hz
White BalanceAWB / MWB
Wide Dynamic RangeWDR Supported
Digital Noise Reduction2D / 3D DNR
Image AdjustmentBrightness, Saturation, Sharpness, Contrast, Denoise
Adjustment Range0–100%
Light ControlAutomatic / Manual
Light BrightnessAdjustable, 0–100%

Video Encoding & Streaming

SpecificationDetails
Video CompressionH.265 / H.264
Video StreamingDual Stream
8MP Main Stream3840 × 2160 at 20 FPS (Default)
6MP Resolution3072 × 2048 at 30 FPS
5MP Resolution2592 × 1944 at 30 FPS
4MP Resolution2560 × 1440 at 30 FPS
3MP Resolution2304 × 1296 at 30 FPS
Additional Resolutions1080P / 720P
Sub Stream720P at 10 FPS
Sub Stream D1704 × 576 at 30 FPS (Default)
Additional Sub Stream Resolutions720 × 480 / 640 × 480 / 640 × 360
Main Stream Bitrate64 Kbps – 8 Mbps
Sub Stream Bitrate64 Kbps – 2048 Kbps
Bitrate ControlVBR / CBR
Video Quality SettingsLevels 1–9
GOP Range1–128
Image SnapshotSub-Stream Snapshot Supported

Image Processing & Display

SpecificationDetails
Image Rotation0° / 90° / 180° / 270°
Image MirroringHorizontal / Vertical / Both
Border CroppingX-Axis / Y-Axis
Privacy MaskSupported
Region of Interest (ROI)Supported
OSD OverlayTime, Camera Title, User OSD, Alarm OSD
OSD Font SizeLevels 1–4
OSD PositionAdjustable
Time DisplayAM / PM Supported
OSD ColorConfigurable

Network & Connectivity

SpecificationDetails
Network InterfaceRJ45 Ethernet
Network Speed100 Mbps
Power over EthernetIEEE 802.3af PoE
RTSPSupported
ONVIFVersion 23.12 Compatible
P2P Cloud ServiceSupported
Remote AccessSupported
Web Browser AccessMultiple Compatible Browsers
PC ClientSupported
Mobile ApplicationSupported
Video Media ServerH.265 / H.264 Dual Stream

Audio, Lighting & Protection

SpecificationDetails
Built-In MicrophoneYes
Night Vision TechnologyInfrared + Warm White Light
Supplemental Lights4 Integrated Dual-Light Illuminators
Illumination Distance98–131 ft (30–40 m)
Lighting ControlAuto / Manual
Weatherproof RatingIP67
Lightning Protection4000V

Recommended Applications

The IPCY 1W 8MP 24/7 MZ DL is suitable for a wide range of professional surveillance installations, including:

  • Residential properties and gated communities

  • Commercial buildings and office complexes

  • Warehouses and distribution centers

  • Retail stores and shopping plazas

  • Parking lots and vehicle entrances

  • Industrial facilities and manufacturing plants

  • Building perimeters and outdoor security

  • Schools, campuses, and institutional facilities

Why Choose the IPCY 1W 8MP 24/7 MZ DL?

The IPCY 1W 8MP 24/7 MZ DL combines 4K Ultra HD imaging, Sony CMOS sensor technology, a motorized varifocal lens, advanced AI detection, and intelligent dual-light night vision in a rugged, professional-grade bullet camera.

Designed for modern network surveillance systems, it provides flexible installation, detailed image capture, intelligent event detection, and dependable outdoor operation.

Whether protecting a home, business, warehouse, or large commercial property, this camera offers an effective combination of high-resolution imaging and advanced security technology.

BOSS SECURITY WORLDWIDE

Professional Security & Surveillance Solutions
